Information
User-Friendly Features: Designed with user-friendliness in mind, featuring a PWM (Pulse Width Modulation) control type and a compact size of 85x59x20mm, making it easy to integrate into various systems.
Compliance with International Standards: The product is certified by CE, ROHS, and ISO9001, ensuring compliance with international standards and regulations, providing users with peace of mind and confidence in its quality and performance.
Features
High Efficiency and Reliability: With a maximum PV power of 344W and a working time of up to 24 hours, this solar charge controller is designed to provide efficient and reliable performance, making it suitable for various applications
Durable and Waterproof Design: Featuring a robust and durable design, ensuring it can withstand harsh environmental conditions and protect against water and dust ingress.
Specifications
12v 24v options
Device consumption: < 4 mA
Open Circuit V: <47v
Module Current: 10A
Load Current : 10A
End of Charge Voltage: 13.9v (27.8v)
Boost Charge Voltage: 14.4v (28.8v)
reconnection voltage (SOC/LVR) >50%/12.4V ... 12.7V (24.8V ... 25.4V)
Deep discharge protection (SOC/LVD): <30%/11.2V ... 11.6V (22.4V ... 23.2V)
Ambient temperature: -25C ... +50C
Terminal: 4mm2 - 6mm2 - AWG 12-9
Degree of protection: IP68
Dimensions (L X W D): 85x59x20mm
Weight: approx 150g
