With 3.2V per cell the Lithium Iron Phosphate (LiFePO4) range is ideally suited for replacement of equivalent size SLA with the extra benefits of up to 8 times the cycle life, greater utilisation of available capacity through increased Depth of Discharge (DOD) and fast charging. All of this at close to half the weight makes them ideal for deep cycle and mobility applications.
Length: 180mm
Width: 76mm
Height: 166mm
Information
This Lithium Iron Phosphate (LiFePO4) range now comes with IEC Certification on both the BMS and Cells. This certification has been obtained through thorough testing of the product and a complete audit of the factory. The IEC Certification is a huge tick of approval for safety and quality, and peace of mind.
As well as utilising LiFePO4 technology, this Lithium Iron Phosphate (LiFePO4) range of batteries also includes a built in Battery Monitoring System (BMS) to further protect against over charge / discharge, over temperature as well as managing internal cell balancing which is critical for the safety of the battery and all of this in flame retardant casing. As an added benefit, Phosphate is not a hazardous material and so is friendly both to the environment and health.
MASSIVE 7yr Manufacturer warranty (You must complete and register via the provided Warranty card)
Features
Feature & Benefits
*Greater number of cycles (2500 ) along with greater utilisation of available capacity (up to 100% DoD) depth of discharge, means up to 8 times the cycle life of standard SLA technology – lowering your total cost of ownership.
*Integrated battery management system (BMS) – Provides optimum safety and performance.
*Safe and stable chemistry – The use of LiFePO4 along with integrated BMS greatly reduces the risk of combustion or explosion due to high impact, overcharging or short circuit situations.
*Higher energy density means this Lithium Iron Phosphate (LiFePO4) battery is close to half the weight of an equivalent SLA making them ideal for mobility and weight critical applications.
*Extra FAST CHARGING and we "still" recommend Lithium Battery Chargers for Lithium Batteries
*Rugged plastic flame retardant case and cover.
*UL1642 at cell level
*Three year warranty approved application
Specifications
Voltage: 12.8V
Capacity: 20Ah
Technology Charged: Secondary (Rechargeable)
Standard Charge Current: 10 Amps (0.5C)
Standard Current Charge Time: 2 hours at 0.5C
Quick Charge Current: 20 Amps for 1 hour (1C)
Technology: Lithium Iron Phosphate (LiFePO4)
Weight: 3kg
Length: 180mm
Width: 76mm
Height: 166mm
Termination: M6 (Bolt-in)
Applications
Applications
*Mobility Devices
*Caravan and camping
*Solar energy Storage
*UPS and Critical power
*Personal power packs
*Medical Equipment
*Recreational, Sports, Outdoor and Indoor Applications where Power Storage and supply are required
