The new and improved Charge N’ Maintain is perfectly suited to the DIY’er. No fuss options mean you can simply hook them up and the charger will do the rest. Projecta’s Charge N’ Maintain range offers a safe and practical method for charging all your automotive and marine batteries.
BIG VALUE!!
Click image for more options.
Information
This technology offers switchable charging stages that ensure an accurate and efficient charge for your battery. This allows longer life and better performance for your battery over extended periods of time.
These Smart Chargers communicate with the battery and ascertain its level of charge. This allows the charger to balance its load and optimise its charging methods to ensure charging is stopped when the battery reaches capacity.
Features
Lightweight & Compact
Switch Mode Technology converts 240V power to 12V DC using electric components, unlike traditional chargers with heavy transformers.
Safe & Easy to Use
The Charge N’ Maintain range are spark-free and are protected against accidental reverse connection significantly increasing safety. They are safe to use while the battery is still in the vehicle; simply connect and forget.
Weatherproof
The chargers are IP65 rated ensuring they’re reliably weatherproof.
Easy-to-read Status Indicators
The colour code charge indicators show POWER on, CHARGING and FULLY CHARGED. (AC008/AC015). The LCD screen displays charge information for ease of use. (AC040/AC080).
Adjustable output
Output is adjusted to suit different battery sizes for optimum charging.
Hard-wiring
Inter-changeable fused wiring harness for permanent installation.
Specifications
INPUT (NOMINAL): 100VAC-240VAC, 50-60HZ
INPUT POWER: 17W
OUTPUT VOLTAGE: 12V
OUTPUT CURRENT: 0.8A
CHARGING STAGES: 4
1. BATTERY HEALTH CHECK: 0.8A UP TO 10.0V
1A. STOP CHARGING: If battery voltage has not reached 10.0V within 2 hours Stage 1, stop charging. Set error.
2A. BULK: 0.8A to 14.4V
2B. BULK TIMEOUT, DISPLAY F4, STOP CHARGING, 22 HOURS ± 10%
3A. ABSORPTION VOLTAGE HOLD FOR 30 MINS TRANSIT TO FLOAT 14.4V
4. FLOAT VOLTAGE MAX VOLTAGE IS 13.5V FOR 2 MIN OR CURRENT <0.3A, THEN OFF FOR 3 MIN. REPEAT 13.5V for 2 mins or <0.3A then 2 mins rest, repeat
BATTERY VOLTAGE DROPS BELOW A SET VOLTAGE RESTARTS BULK: 12.0V
IP RATING: IP65
