12V 20A Charger & 35 Amp Power Supply System

12V 20A Charger & 35 Amp Power Supply System
12V 35 Amp Power Supply System. The entry level system for set-and-forget battery system management. Includes centralised unit for neat and easy wiring of lighting and electricals, 35A power supply, 5 stage charging via DC 100A Voltage Sensitive Relay or 20A charge via AC plug.
Click image for more options.
RRP:
NZ$ 764.72
Price:
NZ$ 604.00 including GST


or four payments of $151.00 with
Afterpay Payment Offer Learn More

TBCPM100
In Stock
Purchase Qty:


This unit connects your service/caravan battery to the vehicle starter battery and ensures alternator charge prioritises the starter battery first. It protects the voltage of the starter battery so you can start your car every single time, even with a heavy load on the auxiliary. Features 10 channel fused output via screw terminals, L.E.D status indicators and charge or power supple switch.
*100A for 30mins 60A continuous.

FULL RANGE OF MANAGEMENT SYSTEMS FOR RV'S -CLICK HERE



20A Charger, 35A Power Supply



Charge or Power Supply Switch



LVD to protect the battery from deep discharge



Screw terminals for input and output



Voltage Sensitive Relay engages & disengages with engine

COMPONENTS
TBC/PM100 - 12V 20A Charger & 35 Amp Power Supply

SPECIFICATIONS
12V A Charger
35A Power Supply
100A DC VSR
10 Fused Outputs

WIRING UNIT DIMENSIONS
273mm long
197mm wide
70mm high

OTHER COMPONENTS

PMTEX-2 - 2m Extension Cable for Temperature Sensor
PMTEX-4 - 4m Extension Cable for Temperature Sensor
PMAC - AC Power Cord, 1.5m
PMBS - Battery Sensor with 3m of Cable
PMBEX-2 - 2m Extension Cable for Battery Sensor
PMBEX-4 - 4m Extension Cable for Battery Sensor
PMLCDC - 5m Cable to suit LCD Screen (Crystal Display)
PMSWEX-2 - 2m Extension Cable for Panel Switch, LED and LCD Monitor
PMSWEX-4 - 4m Extension Cable for Panel Switch, LED and LCD Monitor
PMWS200 - 200mm Water Sensor with 4m Cable
PMWS400 - 400mm Water Sensor with 4m Cable
PMWEX-4 - 4m Extension Cable for Water Sensor

COMPREHENSIVE INSTRUCTION MANUAL INCLUDED WITH YOUR PURCHASE
