A GAME CHANGER FOR PORTABLE (OR FIXED) POWER.
POWER SUPPLY, BACK-UP POWER, EMERGENCY POWER. USE THE SAME POWER SUPPLY FOR YOUR DIFFERENT APPLICATIONS -just take and plug in.
"Stackability" of additional batteries available for this unit.
Information
All-round Upgraded Expandable Power Station
Expandable power station with 2,048Wh LiFePO4 cells and 2,200W pure sine wave inverter. Your mobile power center at home or on the way.
Coffee Maker(1150W): 1.5Hrs
Electric Drill(1650W): 1.5 Hrs
Refrigerator 150W(1200W): 10 Hrs
Air Conditioner(5000 BTU): 1-4 Hrs
CACP(40W): 30-40 Hrs
Light(10W): 150+ Hrs
Less To Spend, More To Love
Struggling between power and flexibility? We got you covered! With two expansion ports, This Unit welcomes up to two 2048Wh battery packs (Sold separately) or up to two 3072Wh battery packs (sold separately), connecting of which can boost the total capacity to a staggering 8192Wh!
Features
Get Charged In Anyway You Prefer
This unit allows up to 900W of solar input and 500W via the adapter, you can even charge it up via your wall outlet and solar panels simultaneously, boost a stunning 1400W total charging rate which can top up your power beast in less than two hours! Further more, every battery module has their own input port for AC adapters, you’ll get another 500W of input capability with every module added (Up to two for the TBCAC200MAX P/S).
Small Change, Huge Leap
The TBCAC200MAX P/S can now take one module via its solar input port with a converter cable for extra capacity!
Incomparable Outlet Versatility
With 15 outlets, you get to run all your needs simultaneously without breaking a sweat.
Specifications
BATTERY INFO
Capacity: 2048Wh (51.2V,40Ah)
Cell Chemistry: LiFePO4 (Lithium Iron Phosphate)
Lifecycle: 3,500+ Cycles to 80% Original Capacity
Shelf-life: Recharge to 80% Every 3-6 Months
Management System: MPPT Controller, BMS, etc
OUTPUT
AC Output: 4 x 220V-240V, 2200W In Total
Inverter Type: Pure Sine Wave
Surge Power: 4800W
USB-C Port: 1 x 100W Max.
USB-A Port: 2 x 5V/3A USB-A
2 x 18W USB-A
12V DC Outlets: 1 x 12V/30A (RV Outlet)
1 x 12V/10A (Car Outlet)
2 x 12V/10A DC 5521 (5.5mm Outlet)
*All Regulated.
Wireless Charging Pad: 2 x 15W Max. (For Each)
INPUT
AC Adapter Input: 500W.
Solar Input: 900W Max.OCV 10-145VDC, 15A
Car Input: 12/24V from Cigarette Lighter Port
Max Input: 1,400W, with AC+Solar Input
RECHARGE TIMES
AC Adapter (500W): ˜5.5~6 Hours
Solar (900W): ˜3~3.5 Hours (With prime sunshine, ideal orientation and low temperature)
12V/24V Car Outlet (100W/200W): ˜10 or 20 Hours
AC Adapter + Solar (1400W): ˜2.0~2.5 Hours (With prime sunshine, ideal orientation and low temperature)
Dual AC Adapters (1000W): ˜3~3.5 Hours (Extra adapter is REQUIRED)
GENERAL
Scalability: Expandable w/ Up to two 2048Wh battery packs (Sold separately) or up to two 3072Wh battery packs (sold separately)
Pass-through Charging: Yes
Weight: 61.9lbs (28.1kg)
Dimensions (LxWxD): 16.5 x 11 x 15.2 in ( 42 x 28 x 38.65cm)
Operating Usage Temperature: -4-104? (-20-40?)
Storage Temperature: 14-113? (-10-45?)
Certification: UL Standard, CEC, DOE, FCC, CA Prop 65
