HIGH QUALITY, ROBUST CONSTRUCTION, Monocrystalline Photovoltaic Panel
Monocrystalline, the most efficient Panel and most suited to NZ conditions.
23.4% Efficiency making this product one of the best Solar supply options on the market.
When used in conjunction with our Lithium Power stations, they become the perfect power generation and supply units.
Also being foldable allows you to reduce the power supply to maintain charged and stored batteries/power stations.
Information
Solar Charge Anywhere
Connect it and leave it. Set to keep your batteries juiced as long as there is sunlight available.
USE for solar application, or combine with the new Lithium Power Stations to complete your power requirements.
23.4% High Efficiency
Built with monocrystalline solar cells, can convert up to 23.4% of sunlight into solar energy, charging your batteries even in bad weather.
Features
Easy Setup With Kickstand
Unfold, snap the kickstands, adjust the angle to maximize the amount of sunlight, and you're ready to harness solar energy for your batteries.
Built to Last
The ETFE coating and IP65 junction box are designed to withstand any scratches and watersplash, perfect for camping, fishing, hiking and much more.(where possible avoid exposure to rain, whilst water resistant it is not waterproof, prolonged exposure to constant rain may adversely affect performance)
Portable in Every Way
Specifications
Specifications
POWER
Model:PV120
Power:120W
Lamination:ETFE (Ethylene tetrafluoroethylene)
Cell Type:Monocrystalline Silicon
Cell Efficiency:Up to 23.4%
Voltage at Max Power(Vmp):19.6V
Current at Max Power(Imp):6.1A
Open Circuit Voltage(OCV):24.4V
Short Circuit Current(Isc):6.43A
GENERAL
Connector:Standard MC4 Connector
Weight:12.57lbs (5.7kg)
Dimensions (Unfolded):21 × 65in (53.3 × 165.2cm)
Dimensions (Folded):21 × 18.5in (53.3 × 47cm)
Operating Temperature:14-149F (-10 - 65C)
Best Working Temperature:77F (25C)
Cable Length:118in (3m)
Certifications:FCC, CE, ROHS
