Charger type Six step, fully automatic charging cycle
Battery types All types of 12V lead-acid batteries (WET, MF, Ca/Ca, AGM and GEL)
Battery capacity 1.2–32Ah up to 100Ah for maintenance
Click image for more options.
Information
The unique display allows the user to follow the entire charging process. The XS 0.8 is a compact and fully automatic 6-step charger for 12V batteries from 1.2-32Ah and is suitable for maintenance charging up to 100Ah. The XS 0.8 is IP 65 classified (splash and dust proof), delivers 0.8A and is designed to protect vehicle electronics. It is non-sparking, reverse polarity protected and short-circuit proof. The XS 0.8 is delivered with 5-year warranty.
Specifications
Auto: Fully automatic for optimal charging
12V: For all lead-acid batteries
Step 5: Fully Charged Battery
Step 6: Maintenance Charging
Model number 1047
Volt 12V
Rated Voltage AC 220–240VAC, 50–60Hz
Charging voltage 14.4V
Min battery voltage 3.7V
Charging current 0,8A max
Current, mains 0.2A rms (at full charging current)
Back current drain <1Ah/month
Ripple <4%
Ambient temperature -20°C to +50°C, output power is reduced automatically at high temperatures
Charger type Six step, fully automatic charging cycle
Battery types All types of 12V lead-acid batteries (WET, MF, Ca/Ca, AGM and GEL)
Battery capacity 1.2–32Ah up to 100Ah for maintenance
Dimensions 145 x 55 x 38mm (L x W x H)
Insulation class IP65
Weight 0.4kg
