34 Optima Battery Red Top Starting 12v

Name: 34 Optima Battery Red Top Starting 12v
Brand: The Battery Cell
SKU: 34
Price: 572.00 NZD
Availability: InStock

> Home > FULL BATTERY RANGE > optima batteries USA > 34 Optima Battery Red Top Starting 12v

The Power of 12v High Crank starting Spiral AGM tech!! QUALITY
-Strongest five-second starting burst, Up to two times longer life, More than 15 times the vibration resistance, Completely spillproof, mountable in virtually any position, Maintenance-free, Faster recharging, Optimal starting power

Other Collection locations available for this product are:
Whangarei (Central), Auckland (Albany), Auckland (Mangere), Hamilton (Burbush), Tauranga (Mt. Maunganui), Pamlerston North (Takaro), Wellington (Petone), Wellington (Seaview), Nelson (Central), Christchurch (Yaldhurst), Dunedin (Central)
YOU CAN ONLY COLLECT THIS ITEM FROM THE OTHER LOCATIONS if you order it separately from other product.

RRP:

NZ$ 621.00

Price:

NZ$ 572.00 including GST

or four payments of $143.00 with
Learn More

UOM:

ea

Product Code:

34

Stock Status:

In Stock

Availability:

FAST Delivery or Collection from Various Locations

Information
Features
Specifications
Product Enquiry
Associated Items

OPTIMA REDTOP 34 Ultra high-performance SPIRALCELL TECHNOLOGY AGM (absorbent glass mat) battery with reliable cranking power for your auto, car or truck and twice the life. The OPTIMA REDTOP will outperform and outlast traditional batteries in demanding cranking/starting applications. The ultimate high-CCA starting battery for vehicles that have alternators capable of keeping up with all electrical loads.

If you have demanding electrical accessory loads such as winches, audio systems, and other devices, take a look at the YELLOWTOP (D34) product line.

The OPTIMA model number for this battery is 34. If you are replacing an OPTIMA battery you already have, this model is the same as batteries marked 8004-003, 9004-003, 27990, 34-78, 34/78-980, RED34/78, SC34U, or N9934/78RED or 34.

Performance Data
Cold Cranking Amps:	800
Cranking Amps:	1000
Nominal Voltage:	12 volts
Open Circuit Voltage (fully charged):	12.8 volts
Internal Resistance (fully charged):	0.0030 ohms
Capacity:	50 Ah (C/20)
Reserve Capacity:	BCI: 100 minutes (25 amp discharge, 80°F (26.7°C), to 10.5 volts cut-off)

Physical Characteristics
Plate Design:	High purity lead-tin alloy. Wound cell configuration utilizing proprietary SPIRALCELL TECHNOLOGY.
Electrolyte:	Sulfuric acid, H₂SO₄
Case:	Polypropylene
Case Color:	Dark Gray
Cover Color:	“OPTIMA“ Red
Group Size:	BC I: 34/78
Post Type:	Dual SAE/GM
Weight:	38.8 lb
Length:	265mm
Width:	172mm
Height:	199mm

Power
CCA (BCI 0°F):	800 amps
MCA (BCI 32°F):	1000 amps

Recommended Charging
The following charging methods are recommended to ensure a long battery life: (Always use a voltage regulated charger with voltage limits set as described below.) Model: 34/78 These batteries are designed for engine starting applications. They are not recommended or warranted for use in deep cycle applications.

Recommended Charging Information
Alternator:	13.3 to 15.0 volts; no amperage limit
Battery Charger:	13.8 to 15.0 volts; 10 amps maximum; 6-12 hours approximate
Float Charge:	13.2 to 13.8 volts; 1 amp maximum current
Rapid Recharge (Constant voltage charger):	Max imum voltage 15.6 volts. No current limit as long as battery temperature remains below 51.7°C. Charge until current drops below 1 amp. All limits must be strictly adhered to
